APC Back UPS Pro Uninterruptible Power Supply – BR1500MS2

Availability

Customizable Voltage Sensitivity – Toggle between pre-determined voltage-transfer points depending on your power quality (high; medium or low sensitivity); maximizing useful battery life and protecting sensitive electronics.

Boost and Trim Automatic Voltage Regulation – Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).

Cold-start Capable – Provides temporary battery power when the utility power is out.

Automatic Self-test – Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Battery Failure Notification – Provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Intelligent Battery Management – Maximizes battery performance; life; and reliability through intelligent; precision charging.

Transformer-block Spaced Outlets – Protect equipment with input transformer blocks without blocking access to other receptacles.

Customizable Voltage-transfer Points – Adjust the voltage points (widen or tighten the range) where your UPS transfers to battery to maximize useful battery life and protect sensitive electronics.

Green Mode – Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Protection

Battery and Surge Protected Outlets – Back up and protect your hardware and data during power outages; surges and spikes.

Dataline Surge Protection – Provides protection of connected equipment from power surges on the data lines.

Surge Only Outlets – Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Safety

Safety-agency Approved – Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Manageability

LCD Status Display – Provides key UPS status at a glance. Multiple status indicators with load and battery bar graphs.

USB Connection – Use your PC to access additional power protection and management features for your UPS via a USB Port.

Audible Alarms – Provides notification of changing utility power and UPS power conditions.

Disconnected Battery Notification – Warns when a battery is not available to provide backup power.

Serviceability

Resettable Circuit Breaker – Easy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs).

Simple Battery Replacement – Increases UPS availability by allowing quick; easy battery replacement.

Marketing Features

Battery-protected and Surge-only Outlets – Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment.

Boost Automatic Voltage Regulation (AVR) – Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.

Specifications

Output

• Max Configurable Power (Watts): 900Watts /1.5kVA
• Output Frequency (Sync to Mains): 60 Hz +/- 3 Hz Sync to mains
• Topology: Line interactive
• Waveform Type: Sine wave
• Transfer Time: 8ms typical: 10ms maximum
• Output Connections: (6) NEMA 5-15R (Battery Backup); (4) NEMA 5-15R (Surge Protection)
• Nominal Output Voltage: 120V

Input

• Input Frequency: 60 Hz +/- 3 Hz
• Input Voltage Range for Main Operations: 88 – 147V
• Nominal Input Voltage: 120V
• Input Connections: NEMA 5-15P
• Number of Power Cords: 1
• Cord Length: 6 ft. (1.8 meters)
• Maximum Input Current: 12.0 A

Batteries and Runtime

• Battery Type: Lead-acid battery
• Included Battery Modules: 1
• Typical recharge time: 16 hour(s)
• Replacement Battery: APCRBC163
• RBC Quantity: 1
• Battery Charge Power (Watts): 16Watts
• Battery Volt-Amp-Hour Capacity: 257
• Run Time for Load: 4m 7s

Communications and Management

• Control Panel: Multifunction LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm

Surge Protection and Filtering

• Surge Energy Rating: 1080 J
• Data Line Protection: Coaxial cable for CATV/SATV/modem/audio-video; RJ45 10/100/1000 Base-T Ethernet protection
• Filtering: Full time multi-pole noise filtering: 5% of IEEE surge let-through: zero clamping response time: instantaneous

Environmental

• Operating Temperature: 32 – 104 F degrees (0 – 40 C degrees)
• Operating Relative Humidity: 0 – 95 (Non-condensing) %
• Operating Elevation: 0 – 10000 ft. (0 – 3048 meters)
• Storage Temperature: -15 – 40 C degrees
• Storage Relative Humidity: 0 – 95 (Non-condensing) %
• Storage Elevation: 0 – 10000 ft. (0 – 3048 meters)
• Audible noise at 1 meter from surface of unit: 45 dBA

Conformance

• Approvals: Energy Star V2.0 (USA); FCC part 15 class B; NOM; TUV C-US certified
• Standards: FCC Part 15 class B

Physical

• Maximum Dimensions (W x D x H): 3.94 x 14.49 x 10.24 in.
• Net Weight: 27.56 lbs. (12.5kg)
• Color: Black
• Units per Pallet: 16

Standard Warranty

• Warranty: 3 year repair or replace
