APC Battery Backup – BV400XU

Manageability

LED Status Display – Quickly understand unit and power status with visual indicators.

Audible Alarms – Provides notification of changing utility power and UPS power conditions.

Marketing Features

Battery-protected and Surge-only Outlets – Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment.

Availability

Battery Failure Notification – Provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Automatic Self-test – Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Intelligent Battery Management – Maximizes battery performance; life; and reliability through intelligent; precision charging.

Protection

Surge Only Outlets – Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Battery and Surge Protected Outlets – Back up and protect your hardware and data during power outages; surges and spikes.

Safety

Safety-agency Approved – Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Specifications

Output

• Max Configurable Power (Watts): 220 Watts / 400VA
• Output Frequency (Sync to Mains): 50/60 Hz +/- 5 Hz Sync to mains
• Topology: Standby
• Waveform Type: Stepped approximation to a sinewave
• Transfer Time: 6ms typical: 10ms maximum
• Output Connections: (3) NEMA 5-15R (Battery Backup)
• Nominal Output Voltage: 120V

Input

• Input Frequency: 50/60 Hz +/- 5 Hz Auto-sensing
• Input Voltage Range for Main Operations: 92 – 139V
• Nominal Input Voltage: 120V
• Input Connections: NEMA 5-15P
• Number of Power Cords: 1
• Cord Length: 4.99 ft. (1.5 meters)

Batteries and Runtime

• Battery Type: Lead-acid battery
• Typical recharge time: 8 hour(s)
• Expected Battery Life (years): 3 – 5
• RBC Quantity: 1
• Battery Charge Power (Watts): 7Watts
• Battery Volt-Amp-Hour Capacity: 78

Communications and Management

• Control Panel: LED status display with on line: on battery: replace battery and overload indicators
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm

Surge Protection and Filtering

• Surge Energy Rating: 300 J

Environmental

• Operating Temperature: 32 – 122 F degrees (0 – 50 C degrees)
• Operating Relative Humidity: 0 – 95 %
• Operating Elevation: 0 – 10000 ft. (0 – 3048 meters)
• Storage Temperature: -15 – 50 C degrees
• Storage Relative Humidity: 0 – 95 %
• Storage Elevation: 0 – 50000 ft. (0 – 15240 meters)
• Audible noise at 1 meter from surface of unit: 40 dBA
• Online Thermal Dissipation: 16 BTU/hr

Conformance

• Approvals: California Energy Commission (CEC); cUL listed; Energy Star V2.0 (USA); FCC part 15 class B; TUV C-US certified
• Standards: FCC Part 15 class B

Physical

• Maximum Dimensions (W x D x H): 6.69 x 10.16 x 2.44 in.
• Net Weight: 8.82 lbs. (4kg)
• Color: Black

Standard Warranty

• Warranty: 3 year repair or replace
