APC UPS Battery Backup and Surge Protector – BE850G2

Manageability

LED Status Display – Quickly understand unit and power status with visual indicators.

Audible Alarms – Provides notification of changing utility power and UPS power conditions.

Marketing Features

Battery-protected and Surge-only Outlets – Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment.

Availability

Battery Failure Notification – Provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Automatic Self-test – Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Intelligent Battery Management – Maximizes battery performance; life; and reliability through intelligent; precision charging.

Protection

Surge Only Outlets – Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Battery and Surge Protected Outlets – Back up and protect your hardware and data during power outages; surges and spikes.

Safety

Safety-agency Approved – Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

Product Features:

Adjustable Voltage Sensitivity – Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications

Cold-start Capable – Provides temporary battery power when the utility power is out

Disconnected Battery Notification – Warns when a battery is not available to provide backup power

Hot-swappable Batteries – Ensures clean; uninterrupted power to protected equipment while batteries are being replaced

Simple Battery Replacement – Increases UPS availability by allowing quick; easy battery replacement

Transformer Block Spacing – Connect bulky transformer block plugs without covering up other outlets

USB Connectivity – Provides management of the UPS via a USB port (not available on all models)

Specifications:

Output

• Max Configurable Power (Watts): 450 Watts / 850VA
• Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
• Topology: Standby
• Waveform type: Stepped approximation to a sinewave
• Transfer Time: 6ms typical: 10ms maximum
• Output Connections: (3) NEMA 5-15R (Surge Protection); (6) NEMA 5-15R (Battery Backup)
• Nominal Output Voltage: 120V

Input

• Input frequency: 50/60 Hz +/- 3 Hz Auto-sensing
• Input voltage range for main operations: 92 – 139V
• Nominal Input Voltage: 120V
• Input Connections: NEMA 5-15P
• Number of Power Cords: 1
• Cord Length: 4.99 ft. (1.5m)

Batteries and Runtime

• Battery type: Lead-acid battery
• Typical recharge time: 8 hour(s)
• Replacement Battery: RBC17
• Expected Battery Life (years): 2 – 5
• Battery Charge Power (Watts): 13 W
• Battery Volt-Amp-Hour Capacity: 102
• Run time for load: 2m 23s

Communications and Management

• Interface Port(s): USB
• Control panel: LED status display with on line: on battery: replace battery and building wiring fault
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm

Surge Protection and Filtering

• Surge energy rating: 354 J

Environmental

• Operating Temperature: 32 – 104 F degrees (0 – 40 C degrees)
• Operating Relative Humidity: 0 – 95 %
• Operating Elevation: 0 – 10000ft (0 – 3048meters)
• Storage Temperature: -15 – 45 C degrees
• Storage Relative Humidity: 10 – 90 %
• Storage Elevation: 0 – 50000ft (0 – 15240 meters)
• Audible noise at 1 meter from surface of unit: 45 dBA
• Online thermal dissipation: 19 BTU / hr

Conformance

• Approvals: California Energy Commission (CEC); CSA C22.2 No 107.3; cTUVus; FCC part 15 class B; UL 1778
• Standards: FCC Part 15 class B

Physical

• Maximum Dimensions (H x W x D): 5.47 x 12.87 x 4.13 in.
• Net Weight: 9.04 lbs. (4.1kg)
• Color: Black
• Pallet Dimensions: 47 x 47 x 2 in.
• # of Layers per Pallet: 16
• Pallet Weight: 912.71 lbs.

Standard Warranty

• Warranty: 3 years repair or replace
