Audio-Technica AT-VMN95ML Replacement Stylus for AT-VM95ML Cartridge

Audio-Technica Replacement Stylus for AT-VM95ML

The VM95 Series cartridge with 2.2 x 0.12 mil Microlinear stylus fits half-inch mount turntables. It offers excellent channel separation and low distortion for outstanding tonal quality.

Product Specifications:

Frequency Response: 20-25,000 Hz

Channel Separation: 23 (dB at 1 kHz)

Vertical Tracking Angle: 23

Vertical Tracking Force: 1.8-2.2 g (2.0 g standard)

Recommended Load Impedance: 47,000 ohms

Coil Impedance: 3.3 k ohms (1 kHz)

DC Resistance: 485 ohms

Coil Inductance: 550 mH (1 kHz)

Output Voltage: 3.5 mV (1 kHz, 5 cm/sec.)

Output Channel Balance: 1.5 dB (1 kHz)

Stylus Shape: 2.2 x 0.12 mil Microlinear

Static Compliance: 20 x 10 6 cm / dyne

Dynamic Compliance: 10 x 10 6 cm / dyne (100 Hz)

Recommended Load Capacitance: 100 to 200 pF

Stylus Size: 2.2 x 0.12 mil

Type: VM Stereo Dual Magnet

Package Dimensions: 4.17 x 3.5 x 1.3 inches

Weight: 0.528 ounces
