Cooler Master Hyper 212X CPU Cooler with Dual 120mm PWM Fans, Black

Cooler Master Hyper 212X CPU Cooler with Dual 120mm PWM Fans

A new addition to the widely acclaimed Hyper 212 series, COOLER MASTER Hyper 212X CPU cooler raises the bar for reducing the temperature of your AMD or Intel CPUs even higher. The aluminum fin array adopts X-Vents and Air-Guide to better expel heat away. Up to four direct touch heatpipes pass through the aluminum fin array to create a comprehensive cooling system. Thanks to the fan with redesigned blades, more airflow will be created to cool the heatsink without producing more noise. And the fan’s 4th generation bearing ensures an incredible lifecycle. With COOLER MASTER’s brand-new smart fan engine, the fan will stop once blocked to ensure exceptional protection.

Product Features:

X-Vents Design

Positioned in a 45 degree angle and surrounding the heatpipe, each fin-blade features X-shaped vents that create areas of high and low air pressure, resulting in several controlled vortices. These small and chaotic turbulences produce strong gusts that reduce overall airflow but improve airflow where it matters the most – next to the heatpipes.

Patented “V” Shaped Array

Funnel shaped aluminum fins and a series of perforated dimples guide the airflow towards the heatpipes. Specially designed X-Vents, that act similar to tiny airplane wings and prevent deadspots behind and between heatpipes. The combination of both of these patent technologies results in notably higher airflow over the heatpipes and the adjacent fin area, which ultimately reduces CPU temperatures.

The specially designed X-Vents act similar to tiny airplane wings and prevent deadspots behind and between heatpipes. The combination of these patented technologies results in a notably higher airflow over the heatpipes and the adjacent fin area, ultimately reducing CPU temperatures.

Patented CDC Technology

4 Continuous Direct Contact Heatpipes create a gap-less contact surface for unmatched cooling efficiency.

Optimized Fin Design

Aluminum Fin Array with Tunnel Effect layout creates micro vortices that boost the airflow and circulate it around the heatpipes.

Supports All Current CPU Sockets

Fast and easy to install and extremely reliable, our famous X-Bracket mounting system is compatible with all current sockets.

POM Bearing

The POM bearing is coated with Polyoxymethylene material. This type of material is ideal for precision parts requiring high stiffness and provides consistently lower friction levels than traditional bearings. Self-lubricating, lower friction, and dustproof protection, ensures the average lifetime is pushed up to an incredible 160,000 hours.

Product Specifications:

Product Number: RR-212X-20PM-R1

CPU Socket: LGA2066, LGA2011-v3, LGA2011, LGA1366, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1

Dimensions (L x W x H): 120 x 79 x 158 mm

Heat Sink Dimensions (L x W x H): 116 x 51 x 158 mm

Heat Sink Material: 4 Continuous Direct Contact Heat Pipes, Aluminum Fins

Heat Sink Weight: 492g / 1.1lb

Heat Pipe Dimensions: 6mm

Fan Dimensions (L x W x H): 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch

Fan Speed: 600-2000 RPM (PWM) +/- 10 percent

Fan Airflow: 24.9 – 82.9 CFM +/- 10 percent

Fan Air Pressure: 0.3 – 2.09 mmH2O +/- 10 percent

Fan MTTF: 160,000 Hours

Fan Noise Level: 9 – 36 dBA

Bearing Type: 4th Generation Bearing

Fan Power Connector: 4-Pin (PWM)

Fan Rated Voltage: 12 VDC

Fan Safety Current: 0.37A

Fan Power Consumption: 4.44W (Max)

Fan Weight: 106g / 0.2lb

Warranty: 2 years
