MSI MAG B760 Tomahawk Wi-Fi DDR4 Gaming Motherboard – B760TAMAWIFID4

The MAG series fights alongside gamers in pursuit of honor. with added military-inspired elements in these gaming products; they were reborn as the symbol of sturdiness and durability.

Product Features:

• Supports 12th/ 13th Gen Intel Core; Pentium Gold and Celeron processors for LGA 1700 Socket
• Supports DDR4 Memory; up to 5333+ (OC) MHz
• Enhanced Power Design – 12+1+1 Duet Rail Power System; dual 8-pin CPU power connectors; Core Boost; Memory Boost
• Lightning Fast Game experience – PCIe 5.0 slot; Lightning Gen 4 x4 M.2; USB 3.2 Gen 2×2
• Premium Thermal Solution – Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
• Audio Boost – Reward your ears with studio grade sound quality for the most immersive gaming experience
• High Quality PCB – 6-layer PCB made by 2oz thickened copper and server grade level material

Specifications:

• Operating System: Support for Windows 11 64-bit; Windows 10 64-bit
• CPU:
• Supports 12th/13th Gen Intel Core Processors; Pentium Gold and Celeron Processors
• Processor Socket LGA1700
• Chipset: AMD B760 Chipset
• CPU Socket: LGA1700
• Form Factor: ATX Form Factor
• Memory:
• 4 x DDR4 memory slots; support up to 128GB
• Memory Support 5333 (OC)/ 5200 (OC)/ 5066 (OC)/ 5000 (OC)/ 4800 (OC)/ 4600 (OC)/ 4400 (OC)/ 4266 (OC)/ 4200 (OC)/ 4000 (OC)/ 3800 (OC)/ 3733 (OC)/ 3600 (OC)/ 3466 (OC)/ 3400 (OC)/ 3333 (OC)/ 3200 (JEDEC)/ 2933 (JEDEC)/ 2666 (JEDEC)/ 2400 (JEDEC)/ 2133 (JEDEC)
• Max overclocking frequency:
• 1DPC 1R Max speed up to 5333+ MHz
• 1DPC 2R Max speed up to 4800+ MHz
• 2DPC 1R Max speed up to 4400+ MHz
• 2DPC 2R Max speed up to 4000+ MHz
• Supports Dual-Channel mode
• Supports non-ECC; un-buffered memory
• Supports Intel Extreme Memory Profile (XMP)
• LAN: Realtek 2.5Gbps LAN
• Wireless LAN:
• Intel Wi-Fi 6E
• The Wireless module is pre-installed in the M.2 (Key-E) slots
• Supports MU-MIMO TX/RX; 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps
• Supports 802.11 a/ b/ g/ n/ ac/ ax
• Bluetooth: Supports Bluetooth 5.3; FIPS; FISMA
• Audio:
• Realtek ALC897 Codec
• 7.1-Channel High Definition Audio
• Supports S/PDIF output
• Storage:
• 3 x M.2 Gen4 x4 64Gbps slots
• 4 x SATA 6Gbps ports
• Onboard Graphics:
• 1 x HDMI
• 1 x DisplayPort
• Support HDMI 2.1; maximum resolution of 4K 60Hz
• Support DP 1.4; maximum resolution of 4K 60Hz
• Raid: Supports RAID 0; RAID 1; RAID 5 and RAID 10 for SATA storage devices
• I/O (Rear):
• USB 2.0
• DisplayPort 1.4
• USB 3.2 Gen 2 10Gbps Type-A
• 2.5G LAN ports
• Wi-Fi / Bluetooth Antenna
• HD Audio Connectors
• HDMI 2.1 ports
• USB 3.2 Gen 2×2 20Gbps Type-C
• Optical S/PDIF OUT
• Expansion Slots:
• 2 x PCI-E x16 slot (Qty)
• Supports x16/x4
• 1 x PCI-E x1 slots
• PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
• PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset)
• PCI_E3 PCIe 4.0 supports up to x1 (From Chipset)
• USB (Front):
• 4 x USB 2.0
• 2 x USB 3.2 Gen 1 Type A
• 1 x USB 3.2 Gen 2 Type C
• USB (Rear):
• 4 x USB 3.2 Gen 2 Type A
• 1 x USB 3.2 Gen 2×2 Type C
• 4 x USB 2.0
• Type-C Port: 1 x USB 3.2 Gen 2×2 20Gbps Type-C
• Internal Connectors:
• 1 x Power Connector (ATX_PWR)
• 2 x Power Connector (CPU_PWR)
• 1 x CPU Fan
• 1 x Pump Fan
• 5 x System Fan
• 2 x Front Panel (JFP)
• 1 x Chassis Intrusion (JCI)
• 1 x Front Audio (JAUD)
• 1 x TBT connector (JTBT; supports RTD3)
• 1 x Tuning Controller connector (JDASH)
• 2 x Addressable V2 RGB LED connector (JARGB_V2)
• 2 x RGB LED connector (JRGB)
• 1 x TPM pin header (Support TPM 2.0)
• 4 x USB 2.0 ports
• 2 x USB 3.2 Gen 1 Type a ports
• 1 x USB 3.2 Gen 2 Type C ports
• Product Dimensions (L x W x H): 12 x 9.6 x 2.5 in
• Item Weight: 3.92 lb
• Warranty: 3 Years
