Zoom UAC-2 Two-Channel USB 3.0 SuperSpeed Audio Interface

The UAC-2from Zoom is a 2×2 USB 3.0 audio interface that provides nearly zero latency and supports resolutions of up to 24-bit/192 kHz. Its compact and durable design makes it ideal for both studio and field recording of microphones and instruments, as well as for onstage playback and audio streaming. Furthermore, with dedicated MIDI input and output connectors, it can function effectively as a reliable MIDI interface.

This unit is equipped with two XLR/TRS combo inputs featuring microphone preamps and two balanced 1/4″ outputs. It also offers phantom power for condenser microphones. Additionally, inputs 1 and 2 include a Hi-Z instrument input suitable for guitars and bass. The headphone output is equipped with a dedicated volume control, and a complimentary Mac application is provided for adjusting mix parameters and incorporating effects such as reverb and echo. The interface is powered via USB but can also be powered using the optional AD-14 power adapter. The UAC-2 comes with a USB 3.0 cable and a Steinberg Cubase LE software license card.

• 2-in/2-out USB 3.0 High-Speed audio interface
• Support for recording and playback up to 24-bit/192 kHz
• Ultra-low latency audio streaming (2.2ms roundtrip @ 96 kHz / 32 samples)
• Two combo balanced XLR/TRS input connectors accept both mic and line-level signal
• Hi-Z switches allow direct connection of electric guitar or bass
• Switchable +48V phantom power
• Two balanced TRS output jacks for connection to amplifiers or self-powered speakers
• 1/4″ headphone jack with dedicated level control
• Independent gain controls and clip LEDs for each input
• Large knob output volume control
• Direct Monitoring switch for zero latency monitoring in mono or stereo
• MIDI In and Out
• Compatible with all popular DAW software, including Cubase, Logic, Garage Band, Pro Tools, Ableton Live, and others
• High-performance mic preamps with up to +60dB of amplification
• 120dB of dynamic range
• 4x upsampling during A/D and D/A conversion for reduced noise and enhanced fidelity
• Asynchronous transfer system unaffected by computer jitter
• Bus poweredno AC power required
• Robust metal housing ensures roadworthiness
• Works with all USB 2.0 and 3.0-equipped computers and iPads
